名称Name
|
指 标 Specification
|
| 公称直径 Nominal dicmeter DN(mm) | 150－1300 |
| 允许工作压力 Permissible Working Pressure(Mpa) | PN≤0.25 |
| 允许工作温度 Permissible Working temperature(℃) | 0－200 |
| 玻璃层耐热急变 Glass layer resistance of temperature shock(℃) | 热Heating 120 冷Cooling 110 |
|
DN
|
D
|
D1
|
D2
|
H
|
H1
|
S
|
L≤
|
n－φ
|
总理（kg）
Total Weight
|
|
150
|
130
|
260
|
300
|
49
|
14
|
6
|
1000
|
8-18
|
29
|
|
200
|
190
|
310
|
350
|
49
|
16
|
6
|
1000
|
12-18
|
45
|
|
300
|
300
|
425
|
465
|
49
|
20
|
6
|
1000
|
16-20
|
76
|
|
400
|
400
|
535
|
575
|
49
|
20
|
6
|
1000
|
20-20
|
100
|
|
500
|
500
|
635
|
675
|
49
|
24
|
8
|
1000
|
20-20
|
152
|
|
600
|
600
|
740
|
790
|
59
|
24
|
8
|
1500
|
24-23
|
301
|
|
700
|
700
|
850
|
900
|
69
|
24
|
10
|
1500
|
28-23
|
352
|
|
800
|
800
|
950
|
1005
|
69
|
24
|
10
|
1500
|
32-27
|
416
|
|
900
|
900
|
1050
|
1105
|
69
|
26
|
10
|
1500
|
32-27
|
482
|
|
1000
|
1000
|
1150
|
1205
|
69
|
26
|
12
|
2000
|
36-27
|
752
|
|
1100
|
1100
|
1250
|
1305
|
69
|
28
|
12
|
2000
|
40-27
|
830
|
|
1200
|
1200
|
1350
|
1405
|
69
|
28
|
12
|
2000
|
40-27
|
916
|
|
1300
|
1300
|
1450
|
1505
|
69
|
28
|
12
|
2000
|
40-27
|
974
|
|
DN
|
D
|
D1
|
D2
|
D3
|
D4
|
n—φ
|
b
|
L≤
|
总重（kg）
TTotal Weight
|
|
150
|
130
|
－
|
－
|
202
|
225
|
8-18
|
6
|
1000
|
30.5
|
|
200
|
190
|
－
|
－
|
258
|
280
|
12-18
|
6
|
1000
|
44
|
|
300
|
300
|
380
|
400
|
－
|
－
|
16-20
|
6
|
1000
|
69.5
|
|
400
|
400
|
480
|
500
|
－
|
－
|
20-20
|
6
|
1000
|
90
|
